SKU : N20GM4-H39

N20 metal gear motor N20 DC5V 50 RPM Precision fingerprint lock motor


Applicable motor voltage: DC3V-6V (rated voltage is DC5V)
Motor specifications: 10 * 12 * 15 MM (N20 motor)
Gear box specifications: 10 * 12 MM
Output shaft diameter: 3 MM (with flat position 2.45MM)
Reduction ratio: 1: 256 (estimated)
Weight: 12 g
Rated voltage: DC 5V
Rated load: 200 g.cm
No-load speed: 50 revolutions (plus or minus 10%)
No-load current: 36 MA
At DC3V, the speed is 30 revolutions and the current is 25 MA.
At 6 VDC, the speed is 60 rpm and the current is 45 MA.
