SKU : 5VSM1-C2S1

color: silver
  diameter: 28mm
  voltage: 5v
  no load pull into the frequency:  600hz
  phase: 4
  no load pull out frequency:  1000hz
  reduction ratio: 1 64
  pull in torque:  34.3mn.m 120hz
  step angle: 5.625 x 1 64
  self positioning torque:  34.3mn.m
  dcr: 200ohm plus  7 percent  25 c
  temperature:  40k 120hz
  insulation resistance:  10mohm 500v
  noise:  40db 120hz, no load, 10cm
  dielectric strength: ac 600v  1ma  1s
  insulation class: a
  cable length: 24cm
  suitable for guide wind deflector, portable air conditioner valve, etc

dimensions: 1.65 in x 1.22 in x 0.79 in 4.2 cm x 3.1 cm x 2.0 cm
weight: 1.20 oz 34 g
